Have Some Tough Linear Motion Questions?

View FAQ right on our website [ FAQ Home Page ]

Or, use these product specific pages >>

DualVee

DualVee linear guide wheels consist of both an external and internal 90 degree vee angle. The vee groove guide wheel is made with a double row angular contact bearing for excellent load capability and long life. Vee bearing guide wheels are available in 52100 steel or 440C stainless steel from stock. Other options include seals and shields to meet specific application needs. Special DualVee guide wheels are available for cleanroom, debris-laden, low temperature and high temperature applications.

GV3

GV3 provides a wide array of precision linear guide components utilizing guide wheel androller wheel technology. Slides are available in three different precision grades, ranging from completely ground surfaces to as-drawn quality, to fit performance and economic needs. Lubed-for-life guide wheels come in twin bearings, double row bearings, and compact slimline bearings. GV3 may be used as a simple guide or as a self-actuated rack or belt driven system.

LoPro

LoPro linear actuators are an actuated linear motion system based upon proven DualVee guide wheel technology for smooth and quiet motion over long lengths. Actuation options include AT series belt, ANSI roller chain, lead screw, and ball screw. LoPro linear actuators are also available in a non-actuated version. LoPro linear actuators provide a tough, cost effective, low friction, low profile modular solution, built to withstand a wide range of operating environments. Complete systems include your preference of wiper or basic wheel plates, and may be mounted or un-mounted. Support beams are available in aluminum or steel to meet application demands and to provide ease of installation. A wide variety of gantry brackets are available to form complete LoPro gantry systems.


SL2

SL2 is a completely corrosion resistant linear guide featuring ground stainless steel slides and linear motion bearings. SL2 carriages are made from strong, yet light-weight aluminum alloy. SL2 slides may also be mounted to GV3 beams for further design versatility.




UtiliTrak

UtiliTrak is an ideal choice for running two systems in parallel, where one slide uses DualVee guide wheels and the other uses MadeWell® crowned rollers. Because precise parallelism is difficult to achieve, it is not uncommon for mounting surfaces to be slightly out of parallel. UtiliTrak's design compensates for mounting errors, and does not require absolute parallelism for accurate operation. The DualVee guide wheel carriage assembly and vee channel serves as the motion side, while the MadeWell crowned roller and open channel side allows for parallel misalignment.

PDU2

PDU2's patented wheel technology gives this small belt driven system considerable load capacity for its size. The modular design of the PDU2 allows for quick and easy gantry configuration. Adapter plates can be ordered for connecting PDU2's together, or MCS aluminum framing brackets and extrusion may be ordered to create a machine structure.
PDU2 features an aluminum beam up to 6 meters in length with T-slots, if desired. Aluminum beams without T-slots are ideal for wash down applications, and they will not trap dirt. Additional options for the PDU2 include motor/gearbox mounts, limit and proximity switches, T-nuts, T-slot covers, gearboxes, motors, and electric brake.

Still haven't answered your linear motion question? Comment your question below or email us at mteam@bwc.com!
